KATALOG KODU | PLATE TYPE
THREAD TÜRÜ TEKERLEKLER
THREAD TÜRÜ TEKERLEKLER
Açıklama
Thread türü tekerlekler.
Teknik Çizim
Uygulama
| PLATE TYPE(STANDARD) | ||||||||
| ITEM | HEIGHT | DIAMETER | DYNAMIC LOAD | STATIC LOAD | RIGID | SWIVEL | BRAKE | ESD |
| PT-100-R | 135mm | 100mm | 100kg | 200kg |
 |
|||
| PT-100-R-E | 135mm | 100mm | 80kg | 160kg |
|
|
||
| PT-100-S | 135mm | 100mm | 100kg | 200kg |
|
|||
| PT-100-S-E | 135mm | 100mm | 80kg | 160kg |
|
|
||
| PT-100-S-B | 135mm | 100mm | 100kg | 200kg |
|
|
||
| PT-100-S-B-E | 135mm | 100mm | 80kg | 160kg |
|
|
|
|
| PT-125-R | 160mm | 125mm | 100kg | 200kg |
|
|||
| PT-125-R-E | 160mm | 125mm | 100kg | 200kg |
|
|
||
| PT-125-S | 160mm | 125mm | 100kg | 200kg |
|
|||
| PT-125-S-E | 160mm | 125mm | 100kg | 200kg |
|
|
||
| PT-125-S-B | 160mm | 125mm | 100kg | 200kg |
|
|
||
| PT-125-S-B-E | 160mm | 125mm | 100kg | 200kg |
|
|
|
|
| High precision cone ball-bearing | ||||||||
Castors are an essential element to allow mobility of the assemblies. As well as the standard products shown here we supply very many special castors for higher speeds, heavier loads or special applications. Please contact us to ensure that you receive the castors most suited to your construction.
